FEATURE:
-- High performance, digital standard servo
-- High-precision steel gears
-- Full CNC aluminium hulls and structure
-- High quality brushless motor
-- Dual ball bearings
-- Waterproof
SPECIFICATIONS:
Operating Speed (5.0V): 0.20sec/60 degrees
Operating Speed (6.0V): 0.17sec/60 degrees
Operating Speed (7.4V): 0.13sec/60 degrees
Operating Speed (8.4V): 0.12sec/60 degrees
Stall torque(7.4V):60.0kg.cm(833.40oz/in)
Rated working torque(5.0V):18.0kg.cm(250.02oz/in)
Rated working torque(6.0V):21.0kg.cm(291.69oz/in)
Rated working torque(7.4V):26.0kg.cm(361.14oz/in)
Rated working torque(8.4V):31.0kg.cm(430.59oz/in)
Dimensions(L*W*H): 40X20X39.1mm /1.57X0.79X1.52 in
Weight: 85g (2.99oz)
Connector Wire Length: JR310 mm (12.09in)
Packing Detail:
Transparent plastic box size: 83.5mmx63.5mmx37.5mm weight: 137.3g
Carton box size: 43x26.5x20.5cm 100sets/1CTN Gross weight:14.18kg
Optional Accessories:
BLS7013-001:Offered accessories
BLS7013-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear)
