Specification：
Output Voltage: 5.0V or 6.0V selectable
Continuous output current: 5 Amps
Burst output current: 8 Amps
Input: 6V-16V
Quiescent current: 15mA
Size: 39mm*27mm*15.5mm (L*W*H)
Weight: 25g
Features：
--Designed with an advanced switch mode DC-DC regulator IC, the max efficiency of the chip is up to 92%.
-- With the output short-circuit protection function.
-- Beautiful plastic case, reduce the electromagnetic interference.
--Safe power on with the polarity protection function. If the input polarity is not correct, the UBEC can't work,

but it will not be damaged. What you need to do is just swapping the battery pack's polarity.
--Shows the working status with an indicator (LED), lights when the output is in normal range.

--With a step-down voltage regulator of 0.7V down as an accessory (From 6.0V to 5.3V).

Packing Detail:
Transparency plastic box size: 83.5mmx63.5mmx37.5mm weight: 65.5g
Carton box size: 43x26.5x20.5cm 100sets/1CTN Cross weight: 7kg
