FEATURE:
-- High performance digital standard servo
-- High-precision Taiwan-made metal gears
-- CNC aluminium middle hull
-- High quality brushed motor
-- Dual ball bearings
SPECIFICATIONS:
Operating Speed (5.0V): 0.18 sec/60 degrees
Operating Speed (6.0V): 0.15 sec/60 degrees
Stall Torque (5.0V): 13.89 kg.cm (192.93oz/in)
Stall Torque (6.0V): 16.45 kg.cm (228.49 oz/in)
Dimensions: 40.5X20.2X38.9mm /1.59 X0.80X1.57in
Weight: 60 g (2.12oz)
Connector Wire Length: JR 265 mm (10.43in)
Packing Detail:
Blister size: 113mmx79mmx25mm weight: 97g
Carton box size: 47x25x21cm 96sets/1CTN weight: 9.7kg
Optional Accessories:
KM5515MD-001:Offered accessories
KM5515MD-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear)
