FEATURE:
-- High performance, digital standard servo
-- Full CNC aluminium hulls and structure
-- High quality brushless motor
-- Durable steel gears
-- Dual ball bearings
-- Super long life
-- Waterproof
SPECIFICATIONS:
Operating Speed(5.0V):0.17sec/60degrees
Operating Speed(6.0V):0.14sec/60degrees
Operating Speed(7.4V):0.11sec/60degrees
Operating Speed(8.4V):0.10sec/60degrees
Stall Torque(7.4V):75.0kg.cm(1041.75oz/in)
Rated working torque(5.0V):30.0kg.cm(416.70oz/in)
Rated working torque(6.0V):37.0kg.cm(513.93oz/in)
Rated working torque(7.4V):44.0kg.cm(611.16oz/in)
Rated working torque(8.4V):48.0kg.cm(666.72oz/in)
Dimensions(L*W*H):40X20X38.7mm/1.56X0.78X1.5in
Weight:91.5g(3.22oz)
Connector Wire Length:JR220mm(8.58in)
Packing Detail:
Transparent plastic box size: 83.5mmx63.5mmx37.5mm weight: 143.5g
Carton box size: 43x26.5x20.5cm 100sets/1CTN Gross weight:14.8kg
Optional Accessories:
K8S-001:Offered accessories
K8S-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear)
