FEATURE:
-- Support serial bus daisy chain, 253 ID addresses are optional
-- Adopt TTL communication protocol with strong anti-interference
and long-distance transmission
-- PID available for parameter adjustment , multiple protections,
multiple working modes
-- Fully customizable control, installation at any angle
-- PWM Compatible
-- High-precision metal gears
-- High quality DC motor
-- Dual ball bearings
SPECIFICATIONS:
Operating Speed(5.0V):0.26sec/60degrees
Operating Speed(6.0V):0.21sec/60degrees
Operating Speed(7.4V):0.18sec/60degrees
Operating Speed(8.4V):0.17sec/60degrees
Stall torque(7.4V):40.0kg.cm(555.60oz/in)
Maximum working torque(7.4V):26.0kg.cm(361.14oz/in)
Rated working torque(5.0V):8.0kg.cm(111.12oz/in)
Rated working torque(6.0V):8.5kg.cm(118.06oz/in)
Rated working torque(7.4V):9.0kg.cm(125.01oz/in)
Rated working torque(8.4V):9.5kg.cm(131.95oz/in)
Dimensions:40*20*40.5mm/1.56X0.78X1.57in
Weight:61.5g(2.39oz)
Connector Wire Length:PHB3Pin 175mm(6.82in)
Packing Detail:
Transparent plastic box size: 83.5mmx63.5mmx37.5mm weight: 101g
Carton box size: 43x26.5x20.5cm 100sets/1CTN Gross weight:10.5kg
Optional Accessories:
TTL40-8-001:Offered accessories
TTL40-8-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear)
