FEATURE:
-- Support serial bus daisy chain, 253 ID addresses are optional
-- Adopt RS485 communication protocol with strong anti-interference
and long-distance transmission
-- PID available for parameter adjustment , multiple protections,
multiple working modes
-- Fully customizable control, installation at any angle
-- Full CNC aluminium hulls and structure
-- High-precision steel gears
-- High quality brushless motor
-- Dual ball bearings
-- Waterproof
SPECIFICATIONS:
Operating Speed(5.0V):0.07sec/60degrees
Operating Speed(6.0V):0.06sec/60degrees
Operating Speed(7.4V):0.05sec/60degrees
Operating Speed(8.4V):0.04sec/60degrees
Stall torque(7.4V):40.0kg.cm(555.60oz/in)
Maximum working torque(7.4V):24.0kg.cm(333.36oz/in)
Rated working torque(5.0V):12.0kg.cm(166.68oz/in)
Rated working torque(6.0V):14.0kg.cm(194.46oz/in)
Rated working torque(7.4V):16.0kg.cm(222.24oz/in)
Rated working torque(8.4V):18.0kg.cm(250.02oz/in)
Dimensions:40X20X38.7mm/1.56X0.78X1.5in
Weight:91.5g(3.22oz)
Connector Wire Length:JR220mm(8.58in)
Packing Detail:
Transparent plastic box size: 83.5mmx63.5mmx37.5mm weight: 143.5g
Carton box size: 43x26.5x20.5cm 100sets/1CTN Gross weight:14.8kg
Optional Accessories:
RS40-8-001:Offered accessories
RS40-8-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear)
