FEATURE:
-- Support serial bus daisy chain, 253 ID addresses are optional
-- Adopt RS485 communication protocol with strong anti-interference
and long-distance transmission
-- PID available for parameter adjustment , multiple protections,
multiple working modes
-- Fully customizable control, installation at any angle
-- Full CNC aluminium hulls and structure
-- High-precision steel gears
-- High quality brushless motor
-- Dual ball bearings
-- Waterproof
SPECIFICATIONS:
Operating Speed(7.4V):0.20sec/60degrees
Operating Speed(8.4V):0.18sec/60degrees
Operating Speed(12V):0.12sec/60degrees
Operating Speed(15V):0.10sec/60degrees
Stall Torque(15V):93.0kg.cm(1291.77oz/in)
Rated working torque(7.4V):28.0kg.cm(388.92oz/in)
Rated working torque(8.4V):34.0kg.cm(472.26oz/in)
Rated working torque(12V):40.0kg.cm(555.60oz/in)
Rated working torque(15V):43.0kg.cm(597.27oz/in)
Dimensions:40X20X38.7mm/1.56X0.78X1.5in
Weight:91.5g(3.22oz)
Connector Wire Length:JR220mm(8.58in)
Packing Detail:
Transparent plastic box size: 83.5mmx63.5mmx37.5mm weight: 143.5g
Carton box size: 43x26.5x20.5cm 100sets/1CTN Gross weight:14.8kg
Optional Accessories:
RS75-16-001:Offered accessories
RS75-16-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear)
