FEATURE:
-- Support serial bus daisy chain, 253 ID addresses are optional
-- Adopt RS485 communication protocol with strong anti-interference
and long-distance transmission
-- PID available for parameter adjustment , multiple protections,
multiple working modes
-- Fully customizable control, installation at any angle
-- Full CNC aluminium hulls and structure
-- High-precision steel gears
-- High quality brushless motor
-- Dual ball bearings
-- Waterproof
SPECIFICATIONS:
Operating Speed(12V):0.21sec/60degrees
Operating Speed(24V):0.11sec/60degrees
Stall torque(24V):98.0kg.cm(1361.22oz/in)
Maximum working torque(24V):60.0kg.cm(833.40oz/in)
Rated working torque(9.0V):22.0kg.cm(305.58oz/in)
Rated working torque(24V):37.0kg.cm(513.93oz/in)
Dimensions:40X20X38.7mm/1.56X0.78X1.5in
Weight:91.5g(3.22oz)
Connector Wire Length:JR220mm(8.58in)
Packing Detail:
Transparent plastic box size: 83.5mmx63.5mmx37.5mm weight: 143.5g
Carton box size: 43x26.5x20.5cm 100sets/1CTN Gross weight:14.8kg
Optional Accessories:
RS98-24-001:Offered accessories
RS98-24-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear)
