FEATURE:
-- Support serial bus daisy chain, 253 ID addresses are optional
-- Adopt RS-485 communication protocol with strong anti-interference
and long-distance transmission
-- PID available for parameter adjustment , multiple protections,
multiple working modes
-- Fully customizable control, installation at any angle
-- High-precision metal gears
-- Middle CNC aluminium case
-- High quality DC motor
-- Dual ball bearings
SPECIFICATIONS:
Operating Speed(5.0V):0.27sec/60degrees
Operating Speed(6.0V):0.23sec/60degrees
Operating Speed(7.4V):0.19sec/60degrees
Operating Speed(8.4V):0.18sec/60degrees
Stall torque(7.4V):39.0kg.cm(541.71oz/in)
Maximum working torque(7.4V):23.5kg.cm(326.41oz/in)
Rated working torque(5.0V):8.0kg.cm(111.12oz/in)
Rated working torque(6.0V):8.5kg.cm(118.06oz/in)
Rated working torque(7.4V):9.0kg.cm(125.01oz/in)
Rated working torque(8.4V):9.5kg.cm(131.95oz/in)
Dimensions:40*20*40.5mm/1.56X0.78X1.57in
Weight:64.5g(2.27oz)
Connector Wire Length:PHB3Pin 175mm(6.82in)
Packing Detail:
Transparent plastic box size: 83.5mmx63.5mmx37.5mm weight: 104g
Carton box size: 43x26.5x20.5cm 100sets/1CTN Gross weight:10.85kg
Optional Accessories:
RS39-8-001:Offered accessories
RS39-8-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear
