FEATURE:
-- High performance digital mini servo
-- High-precision steel gear
-- High quality coreless motor
-- Full CNC aluminium hulls and structure
-- Dual ball bearings
-- Super long life
SPECIFICATIONS:
Operating Speed(5.0V):0.14sec/60degrees
Operating Speed(6.0V):0.11sec/60degrees
Operating Speed(7.4V):0.09sec/60degrees
Operating Speed(8.4V):0.08sec/60degrees
Stall Torque(7.4V):25.0kg.cm(347.25oz/in)
Maximum working torque(7.4V):10.0kg.cm(138.90oz/in)
Rated working torque(5.0V):4.0kg.cm(55.56oz/in)
Rated working torque(6.0V):5.0kg.cm(69.45oz/in)
Rated working torque(7.4V):6.0kg.cm(83.34oz/in)
Rated working torque(8.4V):9.0kg.cm(125.01oz/in)
Dimensions:35.5*15*25.3mm/1.38X0.58X0.98in
Weight:40g(1.41oz)
Connector Wire Length:JR320mm(12.48in)
Packing Detail:
Transparent plastic box size:83.5mmx63.5mmx37.5mm weight:90g
Carton box size:43x26.5x20.5cm 100sets/1CTN Gross weight:9.45kg
Optional Accessories:
CLS2509M-001:Offered accessories
CLS2509M-002:1set of gearset, including gears, shafts(not include motor gear)
