FEATURE:
-- High performance, digital high voltage wing servo
-- Full CNC aluminium hulls and structure
-- High quality coreless motor
-- High-precision steel gear
-- Dual ball bearings
-- Super long life
SPECIFICATIONS:
Operating Speed(5.0V):0.19sec/60degrees
Operating Speed(6.0V):0.16sec/60degrees
Operating Speed(7.4V):0.13sec/60degrees
Operating Speed(8.4V):0.11sec/60degrees
Stall torque(7.4V):20.0kg.cm(277.80oz/in)
Maximum working torque(7.4V):13.0kg.cm(180.57oz/in)
Rated working torque(5.0V):5.70kg.cm(79.17oz/in)
Rated working torque(6.0V):7.80kg.cm(108.34oz/in)
Rated working torque(7.4V):8.80kg.cm(122.23oz/in)
Rated working torque(8.4V):10.8kg.cm(150.01oz/in)
Dimensions(L*W*H):30*10*35.5mm/1.17X0.39X1.38in
Weight:28.2g(0.99oz)
Connector Wire Length:JR185mm(7.22in)
Packing Detail:
Transparent plastic box size: 83.5mmx63.5mmx37.5mm weight: 71.6g
Carton box size: 43x26.5x20.5cm 100sets/1CTN Gross weight:7.6kg
Optional Accessories:
CLS2013W-001:Offered accessories
CLS2013W-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear)
TESTING VIDEO CLIP
