Product Detail

CLS0808M--34g 9.5kg.cm,digital,metal gears mini servo

Item: CLS0808M
Gear: Full metal
Spline: Standard 25T
Motor: Coreless motor
Bearing: 2BB
Dead band: 2μs default
Waterproof: No
Operating Voltage: DC5.0~8.4V
Rated working voltage: DC 7.4V
Working frequency: 1520μs/330hz
Working angle: ±63°@800us-2200us
Working temperature: -10℃~+50℃
Storage temperature: -20℃~+60℃
Detail

PATENT PRODUCTS

COUNTERFEITING WILL BE HELD LIABLE

PETENT NO. ZL201822045200.5

FEATURE:

-- High performance, digital Multivoltage mini servo

-- Patent gear chain design,more stable and durable

-- High Precision Helical Gears Structure

-- High-precision metal gears with hard anodizing

-- Full CNC aluminium hulls and structure

-- High quality coreless motor

-- Dual ball bearings

SPECIFICATIONS:

Operating Speed (5.0V): 0.13sec/60 degrees

Operating Speed (6.0V): 0.11sec/60 degrees

Operating Speed (7.4V): 0.08sec/60 degrees

Operating Speed (8.4V): 0.06sec/60 degrees

Stall Torque (5.0V): 5.0kg.cm (69.45oz/in)

Stall Torque (6.0V): 6.0kg.cm (83.34oz/in)

Stall Torque (7.4V): 8.0kg.cm (111.12oz/in)

Stall Torque (8.4V): 9.5kg.cm (131.95oz/in)

Dimensions: 35.5*15*28.5mm /1.38*0.58*1.11in

Weight: 34g(1.2oz)

Connector Wire Length: JR265 mm (10.33in)

Packing Detail:
Transparent plastic box size: 83.5mmx63.5mmx37.5mm   weight: 70g
Carton box   size: 43x26.5x20.5cm   100sets/1CTN   Gross weight:7.45kg
Optional Accessories:

CLS0808M-001:Offered accessories

CLS0808M-002:1set of gearset, including gears, shafts and 2 ball bearings(not include motor gear)
